Connectors Connector A: HDMI Type A Male Connector B: HDMI Type A Male Housing Material: PVC Connector Plating: 24K Gold 3µm Pin Construction: Phosphor Copper Pin Plating: 24K Gold 3µm Dimensions (approx.) WxDxH: 20x34.2x10.9mm (0.79x1.35x0.43in) Cable Construction Length: 3m (9.84ft) Standard: High Speed HDMI with Ethernet Colour: Black Type: Round Jacket Diameter: 7.3mm (0.29in) Jacket Material: PVC Conductor Material: Copper Conductor Gauge: 28AWG Shielding: Copper Braid, 65% Specifications Supported Bandwidth: 18Gbps Maximum Resolution: 4096x2160@60Hz 4:4:4 8bit Nominal Attenuation: 300kHz-825MHz <5dB 825MHz-2.475GHz <5dB 2.475GHz-4.125GHz <12dB 4.125GHz-5.1GHz <20dB Minumum Band Radius: 48mm (1.89in) Operating Temperature: -30°C - 80°C (-22°F - 176°F) Storage Temperature: -10°C - 85°C (14°F - 185°F) ATC Approved: Yes Miscellaneous Packaging Type: Polybag Warranty (Years): 10 Certificated: RoHS, REACH, UL, ATC Purchasing Information No.: 36964 EAN: 4002888369640 This product is also available in other lengths 36960 - 0.3m (0.98ft) 36961 - 0.5m (1.64ft) 36962 - 1m (3.28ft) 36963 - 2m (6.56ft) 36964 - 3m (9.84ft) 36965 - 5m (16.44ft)
- Tipo de producto
- HDMI
- Garantía
- 2 años, excepto cableado AV 10 a 25 años.
- Longitud
- 3m
