Connectors Connector A: Mini DisplayPort male Connector B: HDMI Type A male Housing Material: Mini DisplayPort: PVC HDMI: PVC Connector Plating: Gold plated Pin Construction: Copper Pin Plating: Gold plated Dimensions (approx.) WxDxH: Mini DisplayPort:17.8x10.8x7.9mm (0.7x0.43x0.31in) HDMI: 37.5x20.5x10.5mm (1.48x0.81x0.41in) Cable Construction Length: 0.5m (1.64ft) Standard: HDMI 1.4, DisplayPort 1.2 Colour: Black Type: Round Jacket Diameter: 4.8mm (0.19in) Jacket Material: PVC Conductor Material: Tinned Copper Conductor Gauge: 32AWG Shielding: Aluminum Braid 85% Specifications Supported Bandwidth: 10.2Gbps Maximum Resolution: 3840x2160@30Hz 4:4:4 8bit Nominal Attenuation: 100MHz~450MHz -2.44--5.099dB 450MHz~8100MHz -5.094~32.906dB Minimum Bend Radius: 50mm (1.97in) Operating Temperature: 0°C - 45°C (32°F - 113°F) Storage Temperature: -10°C - 80°C (14°F - 176°F) Miscellaneous Packaging Type: Polybag Warranty (Years): 2 Certificated: CE, FCC, RoHS, REACH, UL & California Proposition 65 Purchasing Information No.: 36925 EAN: 4002888369251 This product is also available in other lengths 36925 - 0.5m (1.64ft) 36926 - 1m (3.28ft) 36927 - 2m (6.56ft) 36928 - 3m (9.84ft) 36929 - 5m (16.44ft)
- Tipo de producto
- Mini DP a HDMI
- Garantía
- 2 años, excepto cableado AV 10 a 25 años.
- Longitud
- 0.5m
