Lente Panasonic ET-D3LEU100
Lente Panasonic ET-D3LEU100 para proyectores 3DLP. R.P. 4K+ 0.397:1 / R.P. WUXGA 0.370:1 / R.P. FULL HD 0.413:1 / R.P. WXGA 0.370:1 / R.P. SXGA+ 0.401:1.
Lens type Ultra-Short-Throw Lens
F value 2.5
Focal Length (f) 8.0 mm (5/16˝)
Screen size 200-600 inches
Throw ratio | 4K+ 0.397:1
Throw ratio | WUXGA 0.370:1
Throw ratio | SXGA+ 0.401:1
Lens-shift*1 | Vertical ±59 %
Lens-shift*1 | Horizontal +29 % – -5 %
Zoom No
Dimensions (W×H×D) 275 x 154 x 428.7 mm (10 13/16˝ x 6 1/16˝ x 16 7/8˝)
Weight Approx. 8.0 kg (17.6 lbs)
Compatible projectors RQ32K/RZ31K Series/RQ22K/RZ21K Series/RQ13K/RZ12K Series/DZ21K2 Series/DZ13K Series
Note *1 Value is for ceiling installations using the PT-RQ22K. Lens-shift value will vary by model. Please see the Throw Distance Calculator for more information: https://panasonic.net/cns/projector/calculator/tdc/. For floor installations, up and right shift will be defined as a positive value. Down and left shift will bedefined as a negative value.
Throw ratio | WXGA 0.413:1
F value 2.5
Focal Length (f) 8.0 mm (5/16˝)
Screen size 200-600 inches
Throw ratio | 4K+ 0.397:1
Throw ratio | WUXGA 0.370:1
Throw ratio | SXGA+ 0.401:1
Lens-shift*1 | Vertical ±59 %
Lens-shift*1 | Horizontal +29 % – -5 %
Zoom No
Dimensions (W×H×D) 275 x 154 x 428.7 mm (10 13/16˝ x 6 1/16˝ x 16 7/8˝)
Weight Approx. 8.0 kg (17.6 lbs)
Compatible projectors RQ32K/RZ31K Series/RQ22K/RZ21K Series/RQ13K/RZ12K Series/DZ21K2 Series/DZ13K Series
Note *1 Value is for ceiling installations using the PT-RQ22K. Lens-shift value will vary by model. Please see the Throw Distance Calculator for more information: https://panasonic.net/cns/projector/calculator/tdc/. For floor installations, up and right shift will be defined as a positive value. Down and left shift will bedefined as a negative value.
Throw ratio | WXGA 0.413:1
