Lente Panasonic ET-D3LEW200
Lente Panasonic ET-D3LEW200 para proyectores 3DLP. R.P. 4K+ 0.693 - 0.913:1 / R.P. WUXGA 0.645 - 0.850:1 / R.P. FULL HD :1 / R.P. WXGA :1 / R.P. SXGA+ 0.699 - 0.921:1.
Lens type Short-Throw Zoom Lens
F value 2.5
Focal Length 13.8–18.1 mm (17/32˝–23/32˝)
Screen size 200-600 inches
Throw ratio | 4K+ 0.693–0.913:1
Throw ratio | WUXGA 0.645–0.850:1
Throw ratio | SXGA+ 0.699–0.921:1
Lens-shift*1 | Vertical ±59 %
Lens-shift*1 | Horizontal ±19 %
Zoom Yes
Dimensions (W×H×D) 250 × 193 × 495 mm (9 27/32˝ x 7 19/32˝ x 19 1/2˝)
Weight Approx. 9.0 kg (19.8 lbs)
Compatible projectors RQ32K/RZ31K Series/RQ22K/RZ21K Series
Note * Value is for ceiling installations using the PT-RQ22K. Lens-shift value will vary by model. Please see the Throw Distance Calculator for more information: https://panasonic.net/cns/projector/calculator/tdc/. For floor installations, up and right shift will be defined as a positive value. Down and left shift will bedefined as a negative value.
